Cryovial Label Sizes and Printer Compatibility Guide
Sizes:
1-2 ml vial size Portrait
Printable area is 1.00" x 1.00". Part # LBL-17WR. The portrait format allows more bar code characters to fit on the label and can be used to print 2D bar codes - PDF 417 and Datamatrix. Fits most cryovials. Packaged for Cab EOS1 printer.
1-2 ml vial size Portrait
2.75" x 1.00". Printable area is 1.3" x 1.00". Part # LBL-02WR. The portrait format allows more bar code characters to fit on the label and can be used to print 2D bar codes - PDF 417 and Datamatrix. Fits most cryovials. Use ribbon RIB-04 or RIB-05 with Zebra GX420t and TLP2844, Brady BBP11, and TSC TTP 343C (one ribbon per approx 1.5 roll of 600).
1-2 ml vial size Landscape
2.75" x 1.0625". Printable area is 1.5" x 1.06". Part # LBL-13WR. Fits most cryovials. Use RIB-05 Ribbon for Zebra TLP2844, GX420t, TSC TTP 343C and Brady BBP11 printers (one ribbon per approx. 3 rolls of 800).
5 ml vial size
625" x 2.25". Part #: LBL-09WR. Portrait label that fits smaller, conical vials (e.g., "eppendorf" tubes). Use ribbon RIB-04 or RIB-05 for Zebra GX420t, TLP2844, Brady BBP11, TSC TTP 343C (one ribbon per approx. 1.75 roll of 600)
